The 2nd Generation DVP-SS2 Series Slim Type PLC Keeps The Basic Sequential Control Functions From The DVP-SS Series PLC But With Faster Execution Speed And Enhanced Real-time Monitoring Capability.

? MPU Points: 14 (8DI + 6DO)

? Max. I/O Points: 494 (14 + 480)

? Program Capacity: 8k Steps

?COM Port: Built-in RS-232 & RS-485 Ports, Compatible With Modbus ASCII/RTU Protocol. Can Be Master Or Slave.

? High-Speed Pulse Output: Supports 4 Points (Y0 ~ Y3) Of Independent High-speed (max. 10kHz) Pulse Output

? Supports PID Auto-tuning: DVP-SS2 Saves Parameters Automatically After The PID Auto Temperature Tuning Is Completed.

? Built-in High-Speed Counters : 1 Phase – 4 Points 10KHz (20KHz Bandwidth) & 2 Phase – 2 Points 5KHz (20KHz Bandwidth)
